A90L-0001-0509

FANUC A90L-0001-0509

  • SanAce120WF 9WF1224H1D03
  • Dimensions: 120*120*40
  • ALPHA SPMi, SVMi, PSMi
  • Parts are stock critical @ DNC.
SKU: a90l-0001-0509 Category: Brand:

Description

A90L-0001-0509

Fanuc A90L-0001-0509 fan used for many Fanuc ALPHA i drives. This Fanuc spare is in stock our version is the SanAce120WF 9WF1224H1D03. This fan Battery externally on 150mm siPS, aiSP, and larger aiSV (160i, 320i) modules for 18kW,22kW, 30kW, 45kW rated spindle and power supply modules. This is a single Fanuc fan with a three pin connector connecting to the ALPHA SPMi, SVMi, PSMi to dissipate heat.

Fanuc used only one manufacturers fans over the years licensed as the A90L00010509, namely Sanyo Denki SanAce120WF with the code 9WF1224H1D03 as its model. As a disclaimer they may be an NMB-MAT 4715KL-05W-B39 equivalent. The fans measure 120mm * 120mm * 40mm and are 24 VDC rated at 0.32 amp. These fans are stock critical parts for our internal repair requirements and are not always available.
