A90L-0001-0576
Fanuc A90L-0001-0576 fan used on 90mm ALPHA i modules. This is a single fan connected via new style interconnect and bolts to the modular framework of the 6200 series of drives. For model 2 thru to 18 of small servo, power supply and spindle modules. The Fan is also marked as a Sanyo Denki SANACE60WF with the code 9WF0624H603.
It is 60*60*20 mm DC24V and rated at 0.15A and sits attached to a yellow plastic frame.
The frame is part of the top of the amplifier, whereas this fan cools down the heatsink. Contact us for more information or order the drive with this fan fitted.
