A06B-6080-H302
Fanuc A06B-6080-H302 servo amplifier module. This ALPHA combines 3 axes drives into one; controlling 3 motors from the CNC. Normally fitted on smaller less demanding CNC machine tools. Fitted with smaller ALPHA power supply modules and accompanying spindle amps; unless in a EDM or robotic configuration.
Model number is SVM3-12/12/20 and utilises Type B interface for encoder feedback circuit. This amplifier is built around wiring board A16B-2202-0781 and control pcb A20B-2001-0950. The axes are rated at 3amp on the two smaller channels L/M and 5.9amp on the larger N channel. Capable of driving very small motor models from a1,a2 on the smaller channel and aC3 or aC6 on larger channel.
As with all of the Fanuc parts that we repair for exchange stock, we have built up an extensive stock of components including intelligent power modules, opto’s, isolation amplifiers and much more. Further we then test the A06B-6080-H302 on our purpose built rigs; which unlike a lot of Fanuc test rigs sold packaged; we can actually control everything properly and run multiple programs, etc. As with all of the parts we supply this unit carries our warranty to protect you from unexpected breakdowns and too get your machine tool back up and running promptly.
If you are unsure whether your A06B-6082-H302 Fanuc ALPHA servo amplifier module is indeed faulty; refer to our Fanuc alarms page specifically for this series: Fanuc ALPHA servo amplifier alarms.
A06B-6080-H302 is normally in stock and we currently have stock of SVM3-12/12/20 for exchange only. This is the quickest way you can get parts to your faulty machine. Alternatively if cost is a more important consideration then we offer extensive repair and testing facilities for these amplifiers.
