A06B-6090-H003
Fanuc A06B-6090-H003 aC Series Servo Amplifier Unit. This amp utilises PWM interface dependant on whether its running as the original C Series (SVUC predecessor) or as a Fanuc ALPHA C series drive system (aSVUC). This 12 amp unit is a single channel unit for small model motor control on CNC machines or robots.
This ALPHA C Servo amplifier unit was controlled via late Fanuc 0-C, 0-D controls and 15B, 16/18B and 21B control systems.
This servo amplifier drive has A16B-2202-0956 wiring PCB fitted not available seperate. Powering motors including 0371 (a1/3000) or 0372 (a2/2000) or if a latter retrofit then earlier 0-0SP, 1-0SP and 2-0SP motors.
For information on whether your drive is causing the issue, please check the seven segment display on the drive, then consult our Fanuc SVU series alarms and fault codes.
A06B-6090-H003 aSVUC is in stock. This drive always carries a warranty on the exchange, repair and if needed and available as a outright sale. The SVUC1-12 is available to order and ship today. Contact us for prices and options on this drive.
