FANUC A02B-0236-C230

  • I Series Operator Panel w/ MDI Unit
  • Includes A86L-0001-0272
  • Test and exchange available.



Fanuc A02B-0236-C230 110 key (hard) Keyboard. This keyboard is both a operator panel, with a built in MDI which normally sits below the either a combined i series system or a stand alone CNC with seperate LCD panel. Can be fitted with many sizes of LCD displays ranging from 8.4, 9.5, 10, 12 inch either colour or mono. The A02B0236C230 square shaped operator / MDI keyboard has a 65 key mdi unit, and a 55 key operator section with lots of blanks for custom PMC configurations. Commonly used on Fanuc i series controls: 0i-TA, 0i-TB systems. This MDI unit is normally fitted on machining centers and has english text on keys (keyboard A86L-0001-0272).

DNC offers exchange, testing facilities and if no exchange available upon calling repair maybe possible.

Additional information


180 Day Warranty
