Fanuc A06B-6104-H211#H520 ALPHA Spindle Module. This GE Fanuc SPM-11HV Spindle amplifier is used in small applications on the CNC machine. This module normally powers 400VAC servo and spindle amplifiers straight from incoming mains in Europe or via transformer in other parts of the world. This drive has 1200v IPM transistor fitted to A16B-2203-0160 wiring board. The control board is shared across many #H520 high voltage spindle modules. Neither board is available seperately from the complete drive.
At DNC we offer A06B-6104-H211#H520 from stock on a service exchange basis when available. Not being a hugely popular part; its normally always available. If time is not so critical then clean, inspection, fault diagnosis, and repair facilities are also available on this SPM-11HV drive. Why not take advantage of our standard 24 hour drive repair turnaround; which will save you money over our exchange prices; though still get your machine up and running in two to three days, courier dependent.
If you are unsure whether the A06B-6104-H211 spindle amplifier is indeed your fault. Check the displays on the SPM and the accompanying drives and consult our ALPHA spindle amplifier module alarm page.
Contact us if you require information on faults, our services such as exchange, repair or testing and stock availability.
