A06B-0315-B002
Fanuc A06B-0315-B002 AC servo motor. Part of S series of servo and spindle motors; this being a model 10S with electrical rating of 12Nm TRQ, 7.6 Amp, 3 phase 150V, max rpm of 2000. Motor has straight shaft non keyed with standard oil seals.
This is Fanuc’s second generation of AC Servo motors built c.1988 onward. The 0315 AC series red cap Model 10S motor was fitted on many different machine tool applications.
This motor is fitted with an incremental 2500 pulse encoder. DNC offer either exchange, new surplus motors for your CNC machine tool, testing fault diagnosis and repair services are available and so is a full backup service – if the motor is not faulty. Click here if you require either the Analog AC axis drive or the Digital AC Servo amps that were normally fitted on machines with this motor generation.
Warranty for all model 10S motors is 12 months.
