A06B-0152-B177

FANUC A06B-0152-B177

  • ALPHA A06B0152B177 Servo Motor.
  • Same Day / 24 hour turnaround
  • Model a30/3000, Straight, Brake, INC
SKU: a06b-0152-b177 Category: Tag:

Description

A06B-0152-B177

FANUC A06B-0152-B177 a30/3000 Servo Motor. This ALPHA model 30 motor series stats are the following: 4.8kW, 30Nm TRQ, 17 Amp, 3 phase 168V @ 200Hz, maximum 3000 RPM speed. Fitted a straight shaft and brake, standard seals and a standard ALPHA incremental encoder this was a very common motor of the series.  Of this generation the 0153 ALPHA series red cap a30/3000 servo motors were fitted on vertically moving axis requiring a brake to lock, when not energized.

DNC offer new and used refurbished motors with warranty on an exchange basis (assuming in stock). Also extensive testing facilities, fault diagnosis, rebuild and repair of the A06B0152B177 is possible, including encoder, bearings, new seals, shafts, front and end shields and more. We also offer stocks of the ALPHA servo amplifier for these motors.
