A06B-0854-B100

FANUC A06B-0854-B100

  • Alpha A06B0854B100#3000 in stock
  • Same Day Testing & Repair
  • 12 month warranty on Exchange / Rebuild.
SKU: a06b-0854-b100 Category: Tag:

Description

A06B-0854-B100

FANUC A06B-0854-B100 a6 Spindle Motors. Info for this motor: Rated at S1 cont: 5.5kw between 1500-4500 rpm, and 3.5kw @ 8000 rpm – Max 44 amp; S2 30min Cont. 13kw between 1500-4500 rpm, and 7.5kw @ 9000rpm – Max 63 Amp – 3 phase – 4 pole class H insulation IP54, 149-214V without brake, straight shaft with rear blowing fan and flange mounted.

This A06B0854B100 motor from the Fanuc ALPHA 6/8000 Series AC spindle motor range is fitted with a standard AC ALPHA spindle feedback for the serial spindle controllers and CNC’s which is available either as exchange, outright surplus, repair, and also testing services. – other Fanuc AC Spindle Motors.

Additional information

warranty

180 Day Warranty
