A20B-1003-0810
Fanuc A20B-1003-0810 Backplane. This PCB is a series 15 control motherboard which acts as a master PCB to the entire Fanuc 15 system. The board connects the BASE0, BASE1, BASE2, Graphics, Axis board(s) too allow from 2-8 axis control on the smaller and simpler FS-15 controls, up to seriously large configurations.
DNC have four Fanuc 15 control systems, a run of the mill 15T and 15M, a 15TF and a 15iM stand alone test rig built by GE Fanuc HQ before their disbandment by Fanuc & General Electric.
This system 15 backplane is available from DNC today either as exchange, or testing and repair can be carried out on this part.
