A90L-0001-0507#A
Fanuc A90L-0001-0507#A fan used for many Fanuc ALPHA i drives. This Fanuc spare is in stock our version is the SanAce40WF 9WF0424F6D04. This fan Battery in an external housing on smaller aiSV, aiSP, aiPS modules from small 2.2, 5.5, 11kw spindle and power supply modules. This is a single Fanuc fan with a three pin connector joining the fan to the ALPHA SPM, SVM, PSM to dissipate heat.
Fanuc used many manufacturers fans over the years licensed as A90L00010507#A. Normally it was the Sanyo Denki SanAce40WF with the code 9WF0624H7D04 as its model. There is also a NMB-MAT version. Both fans measure 40mm * 40mm * 20mm; being 24 VDC rated below one tenth of an amp. These fans are no longer stock critical parts for our internal repair requirements and are always available. Please call us to check. Click here For Fanuc ALPHA drives.
Technical:
- Dimension 40 * 40 * 20mm
- Voltage: 24VDC
- Current Rating: 0.07amp
- Cable Length: 60mm
- Connector: AMP 3 Pin
Manufactured with genuine Sanyo Denki or NMB-MAT fans with the correct type of AMP three pin male connector for heatsink cooling.
