Identify Fanuc Part Numbers

Identifying Fanuc Part Numbers

Need some help identifying what part you have?

Identify Fanuc part numbers start with A and are made up of twelve digits. These are broken up into three blocks of four characters or digits.

  • Some finish with a # on the end followed by three digits. This relates to revision or the software.
  • Some part numbers have a / followed by 3 digits. These three digits relate to the version/revision of the PCB.
  • Always quote any suffix letters and numbers after / or # and we can let you know if they are important in identify FANUC part numbers.
A02B-0###-C### Fanuc MDI/CRT, Fanuc MDI, FANUC MDI/LCD, Operators, Complete CNC Control and Drive Systems.
A03B-08##-C### Fanuc I/O modules full size and half size.
A06B-####-B### Fanuc Motors
A06B-6###-H### Fanuc Drives
A06B-6070-H### Fanuc Alpha Module
A13B-0###-#### Fanuc Tapereaders
A14B-####-#### Fanuc Power Supply Units and Input Power Units
A16B-####-#### Fanuc Control & Drive Boards and PSU
A20B-####-#### Fanuc Drive, System and Power supply pcbs
A50L-0001-0### Fanuc Drive Transistor Modules.
A60L-0001-0### Fanuc Fuse
A61L-0001-00## Fanuc Monitors
A63L-0001-0### Fanuc Connectors, and Sockets
A80L-0001-0### Fanuc Transformers
A86L-0001-0### Fanuc Keyboards and Soft-key
A87L-0001-0### Fanuc Memory
A98L-0001-0### Fanuc Membranes
A98L-0031-0### Fanuc Batteries
A290-05##-V### Fanuc encoder by internal fanuc number
A860-0###-T### Fanuc Encoders
A860-00##-T### Fanuc Tapereaders
N860-####-#### Fanuc Keyboards
